Galv. Hinge Joint Fence devin wire mesh manufacturer from China Anping Yuhang Metal Products Co., Ltd

Price:	80.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: devin wire mesh

Production Capacity: 1000roll per day

Delivery Date: 20days

Type: Woven

Brand Name: devin wire mesh

Means of Transport: Ocean

Packing: builk

Application: Sieving Diversified Pellet

Material: Others

Mesh Size: 10cms

Material: Electro galvanized iron wire, Hot dipped galvanized iron wire, High tensile steel wire
Surface Treatment: Hot dipped galvanized, Ele

Deer Fence
Hinge Joint Knot Field Field Fence
Hinge Joint Fence
Grassland Fence
Field Fence, Soft wire or higg tensile

Deer Fence is also called field Fence and cattle Fence, what is made of hot-dipped zinc coated steel wire, offer high strength and tensile strength, provide safety fencing against fierce striking of cattle, horse or goats. Knotted Wire Mesh Fences make an ideal fencing material for grasslands husbandry.

Deer Fence (Hinge Joint Knot Field Fence)
(Top/Bottom Wire 2.5mm; Other wire: 2.0mm; roll length:50m)
Type Level wire space(inch) Unit weight
(Kg/roll) Roll Dia
(cm)
Warp Wire No. Height
Inch Hole
No. Edge wrap wire Dia(MM)
07/32/6/2.5 4+4 1/2+5+5 1/2+6+7 19.3 25
08/32/7/2.5 3 1/2+3 1/2+4+4 1/2+5+5 1/2+6 20.8 25
08/35/7/2.5 3 1/2+4+4 1/2+5+5 1/2+6+7 21.6 25
08/40/7/2.5 4+4 1/2+5+5 1/2+6+7+8 22.6 25
08/45/7/2.5 4 1/2+5+5 1/2+6+7+8+9 23.6 25
09/39/8/2.5 3 1/2+3 1/2+4+4 1/2+5+5 1/2+6+7 23.9 25
09/49/8/2.5 4+4 1/2+5+5 1/2+6+7+8+9 26.0 25
10/47/9/2.5 31/2+31/2+4+41/2+5+51/2+6+7+8 27.3 25
10/52/9/2.5 31/2+4+41/2+5+5 1/2+6+7+8+9 28.4 25
11/56/10/2.5 31/2+31/2+4+41/2+5+51/2+6+7+8+9 30.8 25
17/79/16/2.5 10cm*13+15cm*2+20cm*2 47 25
The wire diameter can be done as your requirement, and the Horizzntal Spacing can be 30cm, 15cm, 10cm, 7.5cm, 5cm.
